UCX-1x1-C40
SKU: 91310108
ShippingUSB Type-C Docking Station
Details
Bring Collaboration Spaces to the Next Level
The UCX-1x1-C40 USB Type-C docking station enhances and extends the possibilities of a meeting room and allows meeting participants to easily use their own devices such as laptops, and preferred video conference platforms while also utilizing the available assets of the meeting space, just like the HDMI displays, room cameras and other USB peripherals.
Exploit the Possibilities of USB connectivity
The device utilizes the USB-C connectivity for a simplified transmission of 4K video, audio, control signals and power, and allows data speeds of up to 5 Gbps under the USB 3.1 Gen1 and allowing video resolution capabilities up to 4K@60Hz at 4:4:4. Users who connect their laptop or other mobile device via USB-C can also enjoy charging up to 100W, thus eliminating the need to look for a wall plug and to avoid sudden interruption of meetings.
The device is designed to be a centerpiece of any collaboration space, and can be connected to three USB peripherals via USB-A type connectors.
Additional Features and Capabilities
Security is always a key concern to our customers, therefore our engineers ensured that the UCX-1x1-C40 adheres to the strictest security standards.
The Taurus UCX offers noiseless operation, no fan in the device.
In today’s collaboration environments, it is key that the technology offers flexible and versatile ways for participants to unlock the full potential of a collaboration space and to not be limited by the default options offered by their meeting rooms.
The Taurus UCX product family is Lightware’s ground-breaking innovation offered for the increasingly growing demand for cutting-edge solutions in the world of Unified Communications.
The Ultimate Collaboration for Modern Workspaces
Here's the New Taurus UCX
Experience seamless USB-C connectivity with Taurus UCX, offering effortless 4K video, switching, and USB peripheral support for meeting rooms and huddle spaces.
Specification Table
| Video | ||
| Resolution | Up to UHD/4k@60Hz 4:4:4 | |
| Signal Type | DP Alt Mode, HDMI 2.0, HDMI 1.x, DVI | |
| Maximum data rate | 18 Gbps | |
| Maximum pixel clock | 600 MHz | |
| Content protections | HDCP 1.x, HDCP 2.2 | |
| Connector type (IN) | 1x USB-C receptacle with screw locking option | |
| Connector type (OUT) | 1x HDMI receptacle type A with screw locking option | |
| Video processing | Signal parameter measurement | |
| Audio | ||
| Audio mode | Pass-through to the Audio layer | |
| Supported audio formats for pass-through | All HDMI2.0 audio formats | |
| Control | ||
| Ethernet | Control | 1x 100Base-T via RJ-45 for Secure Control |
| USB | Connectors | 1x USB Type C with charging function up to 100W Optional Ethernet access |
| RS232 | Connector | 1x 3Pol Phoenix |
| Symbol rate | between 9600 and 115200 baud | |
| Configuration | Parity: none, odd or ever Stopbits: 1 or 2 |
|
| General | ||
| Powering | External 160W power supply | |
| Dimensions | Width | 246 mm |
| Height | 26 mm | |
| Depth | 150 mm | |
| Operating conditions | Ambient temperature | 0-50oC |
| Relative humidity | 0-90% (non-condensing) | |
| Transportation conditions | Ambient temperature | -20-70oC |
| Relative humidity | 0-95% (non-condensing) | |
| Complience | EN 55032:2015 | |
| IEC 61000-3-3:2013+AMD1:2017 | ||
| FCC CFR Title 47, Part 15, Subpart B | ||
| Warranty | 3 years | |
Comparison Table
| Variant | UCX-1x1-C40 | UCX-2x1-HC40 | UCX-2x2-H40 | UCX-4x2-HC40 | UCX-4x3-HC40 | UCX-4x2-HC40D | UCX-4x3-HC40-BD |
| HDMI input | 1 | 2 | 2 | 2 | 2 | 2 | |
| USB-C connectivity (4K Video, Audio, Data, Power charge) | 1 | 1 | 2 | 2 | 2 | 2 | |
| HDMI output | 1 | 1 | 2 | 2 | 3 | 2 | 3 |
| USB-A 3.1 Gen1 Connection (for USB Devices) | 3 | 4 | 4 | 4 | 4 | 4 | 4 |
| USB-B 3.1 Gen1 Connection (for PC hosts) | 1 | 1 | 1 | 1 | 1 | 1 | |
| USB-C Gen1 Connection (for PC hosts) with Video | 1 | 1 | 2 | 2 | 2 | 2 | |
| USB-C Gen1 Connection (for PC hosts) USB Data only | 1 | 1 | 1 | 1 | 1 | ||
| USB host switching | |||||||
| DANTE/AES67 audio support | |||||||
| Analog audio de-embedding (5-pole Phoenix) | |||||||
| Secure control Ethernet | |||||||
| Utility Ethernet | |||||||
| Configurable Ethernet | |||||||
| GPIO connection | 6 | 6 | 6 | 6 | 6 | 6 | |
| Occupancy sensor connection | |||||||
| RS-232 connection | 1 | 2 | 2 | 2 | 2 | 2 | |
| Welcome Screen |
Features
CEC at the HDMI output
USB 3.1 Gen 1 connectivity for any USB devices
Camera, speakerphone, touch monitor, USB-HID devices etc…
USB-C input connectivity
for 4K Video, Audio, Data, and Power (Video, Audio, Data and Power over a single USB-C connection)
Charging via USB-C up to 100W
Passive, noiseless cooling
Supports HDMI 4K signal formats
4K UHD @60Hz RGB 4:4:4, up to 18 Gbps
