FP-VINX-110P-HDMI-ENC-GES9

Shipping
SKU
91810029
Be the first to review this product

Floorplate AV Over IP Scaling Multimedia Extender with USB K+M and PoE support

FP-VINX-110P-HDMI-ENC is a two-gang form factor LAN based encoder multimedia device to extend HDMI video from a local source to a remote sink. The VINX encoder and decoder devices connect either via a direct CATx cable connection or through a Gigabit Ethernet switch in-between.

Highlighted features

  • Passive, noiseless cooling
  • Fits in 2-gang form factor Carlon boxes suitable for wall, floorbox and lectern mounting
  • USB 1.1 K+M (HID) extension
  • USB 2.0 MSC (Mass Storage Class) extension
  • Built-in website for device configuration
  • Can be remote powered through CATx cable (PoE PD)

Vertical Markets

Education & Training
Corporate
Defense & Intelligence
Esport & Gaming
Rental & Staging
Digital Signage
Medical
Government
Industrial

Our regional offices and dedicated AV experts are at your disposal and would happily assist you finding the most suitable solution for your AV project.

Simply choose your location and get in touch with your Lightware partner today.

Our dedicated Lightware experts are ready to discuss the needs of your AV projects!

EXTENDER * VIRTUAL MATRIX * VIDEO WALL PROCESSOR * KVM EXTENDER

The operation of FP-VINX-110P-HDMI-ENC and VINX decoders can be expanded from a simple point-to-point application to unlimited endpoints for the ultimate in virtual matrix switching, digital signage and signal extension. The extenders include our Advanced EDID Management system and decoders are capable of scaling the video signal up to the maximum supported resolution of 4K UHD @ 30 Hz. The built-in USB ports support KVM function and can also handle USB 2.0 mass storage. The units are HDCP compliant.

One of the most popular of the unique features of VINX is the Video Wall setup, reducing the time needed to install a video wall to a fraction of the time needed with other systems. The feature options include gap and bezel adjustment, which can be performed in batch.

SILENT OPERATION

The efficient design of all VINX models including the wallplate FP-VINX-110P-HDMI-ENC allows passive, fanless cooling. Unlike other third party models in this product category, VINX has noiseless operation, fitting even the most silent application environments.

BUILT-IN CROSSPOINT VIEW

VINX series also features crosspoint view: available in both the free Lightware Device Controller (LDC) management software and the built-in web in the devices, the crosspoint view shows the available input and output ports of all connected encoder and decoder units, and allows switching the signals across them. The signal can also be switched to a video wall output assembled from several VINX units and acting as a single display sink. A special keyboard combination can be linked with various sources to switch signals.

SMART BANDWIDTH MANAGEMENT

The built-in, selectable Video and Graphic Modes optimize streaming and compression to match the transferred media. The Variable Bitrate feature provides an even more accurate adjustment option for smart bandwidth management, adjustable between 10 Mbps and 800 Mbps.

REMOTE POWERING

When connected to a Power-over-Ethernet (PoE) capable switch, there is no need for installing and connecting a local power supply to power the FP-VINX-110P-HDMI-ENC. Hence valuable space can be conserved which is a major advantage in wallplate applications.

FP-VINX-110P-HDMI-ENC-GES4 (91810028) FP-VINX-110P-HDMI-ENC-GES4 FP-VINX-110P-HDMI-ENC-GES4
FP-VINX-110P-HDMI-ENC-GES9 (91810029) FP-VINX-110P-HDMI-ENC-GES9 FP-VINX-110P-HDMI-ENC-GES9
FP-VINX-110P-HDMI-ENC-MKM (91810026) FP-VINX-110P-HDMI-ENC-MKM FP-VINX-110P-HDMI-ENC-MKM
FP-VINX-110P-HDMI-ENC-MKS (91810027) FP-VINX-110P-HDMI-ENC-MKS FP-VINX-110P-HDMI-ENC-MKS
  • Passive, noiseless cooling
  • Compact and silent design in 2-gang form factor suitable for wall, floorbox and lectern mounting
  • Fits in 2-gang form factor Carlon boxes suitable for wall, floorbox and lectern mounting
  • 1920x1080@120Hz/4:4:4, 4096x2160@30Hz/4:4:4 or 60Hz/4:2:0 maximum resolutions (300MHz)
  • HDMI 1.4 and DVI 1.0 compliant
  • USB 1.1 K+M (HID) extension
  • USB 2.0 MSC (Mass Storage Class) extension
  • Designed to be used with 90 degree angled HDMI cables
  • Advanced EDID Management
  • Intuitive control software for device configuration
  • Device control via Ethernet (TCP/IP)
  • Built-in website for device configuration
  • Firmware upgrade through Ethernet
  • HDCP 2.2 and HDCP 1.4 compliant
  • Status LED for video signal detection
  • Supports several embedded audio formats (including PCM, Dolby Digital and DTS)
  • Can be remote powered through CATx cable (PoE PD)

Specifications
Rack mountable No
Enclosure material 1,5 mm steel
Dimensions in mm* 116,3 W x 44 D x 77 H
Dimensions in inch 4.58 W x 1.73 D x 3,3 H

* with front panel attached

Edid Management
EDID emulation Yes, advanced EDID management
EDID memory 80 factory presets, 5 programmable
Supported standard EDID v1.3
Networked AV output
Power over Ethernet (PoE) Yes, (IEEE 802.3af)
Compliance 1000Base-T (IEEE 802.3ab)
HDCP compliance HDCP 1.4
Transferred signals Video, Audio, RS-232, Infrared, Ethernet, USB
Color space RGB, YCbCr
Video delay 2,2 frames (end-to-end)
Supported resolutions at 8 bits/color * up to 4096x2048@30Hz (4:4:4) or 4096x2048@60Hz (4:2:0)
up to 3840x2160@30Hz (4:4:4) or 3840x2160@60Hz (4:2:0)
1920x1080@60Hz (4:4:4) up to 12 bits/color
Audio formats All HDMI2.0 audio formats

* All standard VESA and CEA resolutions up to 300MHz (HDMI1.4) and other custom resolutions up to 300Mhz are supported.

Ethernet port
Connector type RJ45 female connector
Ethernet data rate 10/100/1000Base-T, full duplex with autodetect
Power over Ethernet (PoE) Supported
USB port
Connector type B-type receptacle
USB compliance USB 2.0
Device class HID / Mass storage

COMPARISON TABLES OF AVAILABLE VINX MODELS

Av Ports of Encoders
VINX-120-HDMI-ENC VINX-120AP-HDMI-ENC VINX-120AP-HDMI-ENC-DNT VINX-210AP-HDMI-ENC WP/FP-VINX-110P-HDMI-ENC
HDMI input check check check check check
VGA input cancel cancel cancel check cancel
HDMI local output check check check cancel cancel
Analog audio input cancel check check check cancel
Dante / AES67 Audio output cancel cancel check cancel cancel
Av Ports of Decoders
VINX-110-HDMI-DEC VINX-110AP-HDMI-DEC
HDMI output check check
Analog audio output cancel check
Ethernet and Control Ports
VINX-120-HDMI-ENC VINX-120AP-HDMI-ENC VINX-120AP-HDMI-ENC-DNT VINX-210AP-HDMI-ENC WP/FP-VINX-110P-HDMI-ENC VINX-110-HDMI-DEC VINX-110AP-HDMI-DEC
RJ45 Ethernet check check check check check check check
SFP Ethernet cancel check check check cancel cancel check
RS-232 RJ12 9-pole D-sub 9-pole D-sub 9-pole D-sub cancel RJ12 9-pole D-sub
USB Mini USB Type B USB Type B USB Type B USB Type B USB Type B 4x USB Type A 4x USB Type A
Video Features
VINX-120-HDMI-ENC VINX-120AP-HDMI-ENC VINX-120AP-HDMI-ENC-DNT VINX-210AP-HDMI-ENC WP/FP-VINX-110P-HDMI-ENC VINX-110-HDMI-DEC VINX-110AP-HDMI-DEC
Image resolution 3840 x 2160 @ 30Hz 3840 x 2160 @ 30Hz 3840 x 2160 @ 30Hz 3840 x 2160 @ 30Hz 3840 x 2160 @ 30Hz 3840 x 2160 @ 30Hz 3840 x 2160 @ 30Hz
EDID Management Advanced Management Advanced Management Advanced Management Advanced Management Advanced Management Transparent Transparent
HDCP HDCP 2.2 HDCP 2.2 HDCP 2.2 HDCP 2.2 HDCP 2.2 HDCP 2.2 HDCP 2.2
Scaling cancel cancel cancel cancel check check check
Powering and Mounting
VINX-120-HDMI-ENC VINX-120AP-HDMI-ENC VINX-120AP-HDMI-ENC-DNT VINX-210AP-HDMI-ENC WP/FP-VINX-110P-HDMI-ENC VINX-110-HDMI-DEC VINX-110AP-HDMI-DEC
Local Power  DC 5V DC 12V DC 12V DC 12V DC 5V DC 5V DC 12V
PoE Remote powering cancel check check check check cancel check
RU Width for rack mounting 1/4 1/2 1/2 1/2 cancel 1/4 1/2
Power Rack Tray compatibility check cancel cancel cancel cancel check cancel
