HDMI-3D-OPT-TX210A
Multimode Single Fiber Extender
HDMI-3D-OPT-TX210 extends HDMI 1.4, DVI 1.0 with HDCP over one multimode fiber and transmits video signal with embedded audio to a distance of up to 2500 meters.
Highlighted features
- 1920x1080@120Hz/4:4:4, 4096x2160@30Hz/4:4:4 or 60Hz/4:2:0 maximum resolutions (300MHz)
- HDMI 1.4, HDCP 1.4 and DVI 1.0 compliant
- Single Fiber Technology
- Audio embedding from 3.5mm jack or 5-pole balanced Phoenix connector
- Local monitor output on transmitter
HDMI-3D-OPT-TX210A extends HDMI 1.4 signals over one multimode fiber and transmit video signal with embedded audio to a distance of up to 2500 meters.
The extender was designed to handle HDMI 1.4 digital video signal and analog stereo audio from local inputs or HDMI embedded audio up to eight channel PCM or HBR audio. Analog audio is converted into digital format. The device has a local HDMI video output for monitoring. The video and the embedded audio of the local output is the same as the one transmitted via the OPT link. The HDMI-3D-OPT-TX210A handles HDCP encryption.
Using the factory, custom or transparent EDID emulation the user can fix and lock EDID data on the HDMI connector. Advanced EDID Management forces the required resolution from any video source and fixes the output format conforming to the system requirements.
All devices can be mounted on a rack shelf or used standalone. HDMI-3D-OPT-TX210A is compatible with both OPT series extenders and matrix switchers.
The device features Pixel Accurate Reclocking, a Lightware technology to eliminate jitter and skew generated by low quality sources and multiple daisy-chained devices.
Single fiber technology makes these units fully HDMI and HDCP compliant without need of a second fiber cable or copper connections. The b-idirectional communication required for HDCP handshaking is performed via the same fiber core that transmits the video signal.
Galvanic isolation between source and display helps avoiding ground loops and hum effects. No delay occurs in the signal during optical conversion, the video image is transported without frame latency. This feature is crucial in 3D applications and systems where audio is processed separately.
This device is fully compatible with the MX-HDMI-OPT-IB/OB boards of the MX series modular matrix switchers.
All devices among the Lightware fiber optical product portfolio are designed to assure cross-compatibility. In a standalone application, HDMI-3D-OPT-TX210A/- RAK and HDMI-3D-OPT-RX150RA can work together flawlessly. To simplify installation and reduce costs, The Lightware hybrid modular matrix concept allows connecting these fiber extenders directly to an MX or a 25G Hybrid matrix router.
This product is compatible with most Lightware fiber optical products: for more technical details please consult the compatibility table in the downloadable product brief.
Applications
- Rental and staging
- Long distance lossless HDMI or DVI signal transmission
- Ground loop isolation
- Professional AV systems, conference rooms
- High End home cinema
- Yacht installations
- Built-in Event Manager control automation feature
- Supports HDMI 3D signal formats (frame packing, side-by-side and top-bottom)
- 1920x1080@120Hz/4:4:4, 4096x2160@30Hz/4:4:4 or 60Hz/4:2:0 maximum resolutions (300MHz)
- HDMI 1.4, HDCP 1.4 and DVI 1.0 compliant
- HDCP enable/disable function on input
- HDCP 1.4 compliant
- Uncompressed video up to 9 Gbps datarate (300 MHz pixel clock)
- No signal latency, zero frame delay
- Adjustable analog audio settings (volume, gain, balance)
- Single Fiber Technology
- Audio embedding from 3.5mm jack or 5-pole balanced Phoenix connector
- Dual output with built-in distribution amplifier
- Firmware upgrade through USB
- Supports all embedded audio formats (including PCM, Dolby Digital and DTS high bitrate audio)
- Extension distance up to 2500 meters (with OM3 fiber, 1920x1080p60)
- Cross compatible with OPT series Lightware fiber extenders and I/O boards
- Advanced EDID Management
- Pixel Accurate Reclocking
- Intuitive control software for device configuration
- Device control via RS-232 and USB
- Supports HDMI 4K signal formats (4K UHD @30Hz RGB 4:4:4 or @60Hz YUV 4:2:0, up to 9 Gbps)
- No video compression
- Built-in video test pattern generator
- Local monitor output on transmitter
- Twist-and-lock DC power connector
- Status LEDs (fiber link, signal and HDCP detect)
- Frame Detector (analyze detailed video timings)
- External universal power adaptor
- 5-pole Phoenix balanced analog audio connectors
- 3,5mm audio jack input
- Mounting options for rack, furniture or truss
Specifications | |
Max Video Data rate: | 9 Gbps |
Max Resolution: | Up to 4K UHD 3840×2160@30Hz, 1600x1200@60Hz, FullHD 1920x1080@60Hz |
Video delay: | 0 frames |
HDCP pass through: | yes |
EDID emulation: | yes, Advanced EDID Management |
EDID memory: | Factory preset, 15 user programmable |
EDID support: | 256 byte Extended EDID v1.3 |
Front panel control: | Audio input select button, ShowMe button |
Fiber: | 50/125 SC Multimode (preferred) or 62.5/125 SC Multimode |
Laser wavelengths: | 6channel CWDM |
High speed lanes: | 778; 800; 825; 850 nm |
Low speed lanes: | 911; 980 nm |
Laser class specification: | Class 3R |
Transmitter output OMA***: | -6.25 dBm (worst case) |
Receiver OMA*** sensitivity: | -14.25 dBm (worst case) |
Optical loss budget: | 8 dBm (worst case) |
Analog audio input volume: | -95.625 dB … 0 dB, in steps of 0.375 dB |
Analog audio input level | max 4dBu |
Power supply: | External power adaptor (100 to 240V AC, 50/60Hz) (5V DC, 1A) |
Enclosure: | 1 mm metal |
Dimensions: | 221 W x 100.4 D x 26 H mm |
Compliance: | CE |
Warranty: | 3 years |
Connectors | |
Power: | Twist-to-lock DC connector (2.5 / 5.5 mm) |
Video inputs: | 1x HDMI connector |
Video outputs: | 1x HDMI connector |
Fiber output: | SC receptacle |
Audio input: | 1 x 3.5 mm jack, 1x 5-pole balanced Phoenix |
Serial port: | 3-pole Phoenix |
USB: | mini USB-B |
Maximum extension distances | ||||
OM1 | OM2 | OM3 | OM4 | |
(62.5/125) | (50/125) | (50/125) | (50/125) | |
1080p@60Hz 24 bpp | 250 m | 600 m | 1200 m | 2500 m |
1080p@60Hz 36 bpp | 150 m | 400 m | 800 m | 1300 m |
4096x2048@30Hz 24bpp | Not supported | 350 m | 700 m | 1100 m |
