UCX-4x3-HC40-BD
SKU: 91310094
ShippingUniversal Matrix Switcher with USB-C Connectivity and Dante USB Audio Bridge
Details
Exploit the Possibilities of USB connectivity
The device utilizes USB-C connectivity for a simplified transmission of 4K video, audio, control signals and power, and allows data speeds of up to 5 Gbps under the USB 3.1 Gen1 and allowing video resolution capabilities up to 4K@60Hz at 4:4:4. Users who connect their laptop or other mobile device via USB-C can also enjoy charging up to 100W (120W total), thus eliminating the need to look for a wall plug and to avoid sudden interruption of meetings.
Devices such as laptops that do not come with USB-C connectivity can also be connected quickly and easily, using a combination of HDMI 2.0 and USB 3.1 Gen1 connections without compromising on either video resolution or data speeds.
The device is designed to be a centerpiece of any collaboration space, and can be connected to four USB peripherals via USB-A type connectors.
The device allows up to two hosts to be connected to the system, and also ensures quick and easy switching between these hosts, making this universal switcher a perfect fit for smaller meeting areas, involving 6-12 people.
Additional Features and Capabilities
The switcher also thrives when it comes to audio capabilities, offering analog audio de-embedding features as well as support for DANTE/AES67 network connection. The UCX-4x3-HC40-BD universal matrix switcher with Dante USB Audio Bridge feature facilitates two-way Dante functions, enabling its use in meeting rooms equipped with a Dante microphone or other sources, all without the need for an external DSP or Dante/USB dongle.
Automated room control features are also included through GPIO ports, besides of RS-232 and occupancy sensor connectivity.
Security is always a key concern to our customers, therefore our engineers ensured that the UCX-4x3-HC40-BD adheres to the strictest security standards.
Secure corporate Ethernet interfaces ensure secure device control and configuration under the SSH, SSL and HTTPS standards, whilst the device can also be securely connected to a closed network of room control devices such as wall panels, or routed to the corporate system for additional control options, all via separate Ethernet layers.
The Taurus UCX offers noiseless operation, no fan in the device.
In today’s collaboration environments, it is key that the technology offers flexible and versatile ways for participants to unlock the full potential of a collaboration space and to not be limited by the default options offered by their meeting rooms.
The Taurus UCX product family is Lightware’s ground-breaking innovation offered for the increasingly growing demand for cutting-edge solutions in the world of Unified Communications.
Also available with NIST FIPS 140-2 certified cryptography (SKU: 91360030)
The Ultimate Collaboration for Modern Workspaces
Here's the New Taurus UCX
Experience seamless USB-C connectivity with Taurus UCX, offering effortless 4K video, switching, and USB peripheral support for meeting rooms and huddle spaces.
Specification Table
| Video | ||
| Resolution | Up to UHD/4k@60Hz 4:4:4 | |
| Signal Type | DP Alt Mode, HDMI 2.0, HDMI 1.x, DVI | |
| Maximum data rate | 18 Gbps | |
| Maximum pixel clock | 600 MHz | |
| Content protections | HDCP 1.x, HDCP 2.2 | |
| Connector type (IN) | 2x HDMI receptacle type A with screw locking option | |
| 2x USB-C receptacle with screw locking option | ||
| Connector type (OUT) | 3x HDMI receptacle type A with screw locking option | |
| Video processing | Signal parameter measurement | |
| Audio | ||
| Audio mode | Simultaneous pass-through and de-embedding to the Audio layer | |
| Supported audio formats for pass-through | All HDMI2.0 audio formats | |
| Supported audio formats for de-embedding | Uncompressed | HDMI Stereo embedded Audio can be de-embedded and converted to 2 channel Dante/AES67 streams |
| Control | ||
| Ethernet | Control | 1x 100Base-T via RJ-45 for Secure Control |
| User Data | 2x 100Base-T via RJ-45 for Configurable Ethernet | |
| RS232 | Connector | 2x 3Pol Phoenix |
| Symbol rate | between 9600 and 115200 baud | |
| Configuration | Parity: none, odd or even | |
| Stopbits: 1 or 2 | ||
| USB | Connectors | 2x USB Type C with charging function up to 100W (120W total), Optional Ethernet access |
| 1x mini USB Type B (reserved for service) | ||
| 1x USB Type A (reserved for future developments) | ||
| 1x USB Type B for Host PC | ||
| 1x USB Type C for Host PC | ||
| 4x USB Type A for peripherals | ||
| Room Occupancy Sensor | Connector | 3Pol Phoenix |
| GPIO | Connector | 8Pol Phoenix |
| General | ||
| Powering | External 160W power supply | |
| Dimensions | Width | 246 mm |
| Height | 26 mm | |
| Depth | 150 mm | |
| Operating conditions | Ambient temperature | 0-50oC |
| Relative humidity | 0-90% (non-condensing) | |
| Transportation conditions | Ambient temperature | -20-70oC |
| Relative humidity | 0-95% (non-condensing) | |
| Complience | EN 55032:2015 | |
| IEC 61000-3-3:2013+AMD1:2017 | ||
| FCC CFR Title 47, Part 15, Subpart B | ||
| Warranty | 3 years | |
Features
HDMI Stereo embedded Audio
can be de-embedded and converted to 2 channel Dante/AES67 streams
USB 3.1 Gen 1 connectivity for any USB devices
Camera, speakerphone, touch monitor, USB-HID devices etc…
USB-C input connectivity
for 4K Video, Audio, Data, and Power (Video, Audio, Data and Power over a single USB-C connection)
CEC at the HDMI outputs
Passive, noiseless cooling
USB-C charging up to 100W (120W total)
Variant available with NIST FIPS 140-2
Lightware Crypto Core (UCX-4x3-HC40-BD-LCC, SKU: 91360030)
Separate USB 3.1 Host switching layer
for multiple USB hosts and USB devices
Secure corporate and room utility
Ethernet connectivity
Supports HDMI 4K signal formats
4K UHD @60Hz RGB 4:4:4, up to 18 Gbps
