HDMI-TPX-TX106
SKU: 91580002
ShippingAVX (non-switchable) HDMI 2.0 extender
Details
Extend 4K HDMI Signals
The HDMI-TPX-TX106 and HDMI-TPX-RX106 extenders with AVX technology are Lightware’s newest development and a natural progression from the widely popular HDMI-TPS-TX/RX96 series, allowing users to extend HDMI 2.0 signals up to 4K60 4:4:4 video resolution through a single CATx cable over distances up to 100 meters.
Seamless Connectivity
Beyond the benefits of sending high-resolution video over long distances, the extenders are also capable to handle various connectivity standards, including bi-directional RS-232, command injection over IR (output only) as well as sending and receiving PoC remote powering.
Take Control with EDID Management
HDCP 2.3 and basic EDID management functionality are also among the features offered by these devices, such as their connectivity and easy integration into a wide range of AV operations and with 3rd party devices, such as the Christie Terra projector.
TPX Series
for Seamless AV Connectivity
The TPX Series offers high-performance signal extension and conversion, ideal for professional AV environments. With support for HDMI, DisplayPort, and other formats, TPX ensures reliable, long-distance transmission for demanding installations. Explore more on our product page.
Specification Table
| Video | |
| Resolution | Up to UHD/4k@60Hz 4:4:4 |
| Signal Type | HDMI 2.0, HDMI 1.x, DVI |
| Maximum data rate | 18 Gbps |
| Maximum pixel clock | 600 MHz |
| Content protections | HDCP 1.x, HDCP 2.3 |
| Connector type | 1x HDMI receptacle type A with screw locking option |
| Standards | HDMI 2.0, HDMI 1.4, DVI |
| Ethernet | |
| Control & User Data | 1x 1000Base-T via RJ-45 |
| RS-232 | |
| Connector type | 1x 3Pol Phoenix |
| Symbol rate | between 4800 and 115200 baud |
| Default configuration | 9600 BAUD, 8N1 |
| IR | |
| Connector type | 3.5mm connector (1/8’’ mini-jack) (output only!) |
| EDID management | |
| 1x pass-through or 1x stored (learned) EDID selected by the push button | |
| General | ||
| Powering | External 16W (12V, 2A) | or PoC remote power receiving |
| and PoC remote power sending | ||
| Power consumption (max) | 16W | |
| Thermal dissipation (max) | 54.6 BTU/h | |
| Weight | 476 g (1.05 lbs) | |
| Operating conditions | Ambient temperature | 0-50°C |
| Relative humidity | 0-90% (non-condensing) | |
| Transportation conditions | Ambient temperature | -20-70°C |
| Relative humidity | 0-95% (non-condensing) | |
| Compliance | CE, UKCA | |
| Warranty | 3 years | |
Features
Supports HDMI 4K signal formats
4K UHD @60Hz RGB 4:4:4, up to 18 Gbps
Bi-directional PoC remote powering
Extends HDMI 2.0
audio, Ethernet, RS-232 up to 100m over one CATx cable
HDR and Low Latency Dolby Vision support
